Reconditioned and/or Refurbished Product Notice: These goods have been reconditioned, rebuilt, or remade, as the case may be and no guarantee or warranty of such goods will be honored or fulfilled by any official or licensed importer of such goods. However, any warranty claims will be covered by The Computer Emporium cc, in accordance with our Returns Policy. Please Note: – This product may or may not be in its original packaging – This product may or may not come with original parts and accessories – There may or may not be minor signs of wear and tear on the device 12 Months Limited Warranty (Excludes power Surge and Malicious Damage) KEY FEATURES: – Four Input / Output Card Slots – Configurable Inputs / Outputs – Analog Inputs (with Phantom Power per Channel) – Analog Outputs – Digital Inputs (AES/EBU and S/PDIF) – Digital Outputs (AES/EBU and S/PDIF) – Configurable Signal Processing – Rich Palette of Processing and Logic Objects – CobraNet Audio – 256 Channel, Low Latency, Fault Tolerant Digital Audio Bus – Clear Front Panel LED Indication – Informative Front Panel Display – Bi-Directional Locate Functionality – 12 Control Inputs and 6 Logic Outputs for GPIO Integration – Soundweb London Interface Kit for Third Party Control System Integration (Documentation) – HiQnet Device – Configuration, Control and Monitoring from HiQnet London Architect TECHNICAL SPECIFICATIONS: Front Panel Led Indicators: Per Input: Signal Present, CLIP, SYNC/48V, I/O card type (IN, OUT, DIG, AEC) Other: LCD Display, Conductor active, Network Link active, Data Activity Analog Inputs: Up to 16 electronically balanced on Phoenix Combicon removable screw connectors Mic/Line Inputs: Nominal gain 0dB, electronically switchable up to 48dB,in 6dB steps Input Impedance: 3.5kΩ Maximum Input Level: 20dBu with 0dB input gain, 8dBu with 12dB gain CMRR: >75dB at 1KHz Input Noise (E.I.N.): <-128dBu typical with 150Ω source Phantom Power: 48V nominal, selectable per input A/D Latency: 38.7/Fs Digital Inputs: Up to 16 AES/EBU or S/PDIF on Phoenix/Combicon removable screw connectors Input Impedance: 110 ohm (AES/EBU), 75 ohm (S/PDIF) Sample Rate: 48kHz or 96kHz Sample Rate Conversion: 8kHz-96kHz THD N: <-140dB Latency: 3/Fso (56.581/Fsi) (55.658/Fso) Analog Outputs: Up to 16 electronically balanced on Phoenix/Combicon removable screw connectors Maximum Output Level: 19dBu Frequency Response: 20Hz-20KHz ( 0.5dB/-1dB) THD: <0.01% 20Hz to 20KHz, 10dBu output Dynamic Range: 108dB typical, 22Hz-22KHz unweighted Crosstalk: <-75dB D/A Latency: 28/Fs Digital Outputs: Up to 16 AES/EBU or S/PDIF on Phoenix/Comicon removable screw connectors Output Impedance: 110 ohm (AES/EBU), 75 ohm (S/PDIF) Sample Rate: 48kHz or 96kHz Sample Rate Conversion: 8kHz-96kHz THD N: <-140dB Latency: 3/Fso (56.581/Fsi) (55.658/Fso) Control Ports: 12 inputs and 6 outputs Control Input Voltage: 0 to 4.5v Control Input Impedance: 4.7kΩ to 5V (2-wire mode), >1MΩ (3-wire mode) Logic Output Voltage: 0 or 5V unloaded Logic Output Impedance: 440Ωs Logic Output Current: 10mA source, 60mA sink Watchdog Output: Phoenix/Combicon connector for failsafe control Opto Output Current: 14mA maximum Withstanding Voltage: 80V maximum (Off) Series Impedance: 220Ω (isolated) Control Network: Connectors: RJ45 Ethernet connector Maximum Cable Length: 100m/300ft on Category 5 cable between device and Ethernet switch Digital Audio Bus: Connectors: 2 x RJ45 Ethernet connectors Maximum Cable Length: 100m/300ft on Category 5e cable between devices Maximum Number of Nodes: 60 Latency Per Node: 4( /-1)Fs CobraNet™ Audio Network: Connectors: 2 x RJ45 connectors Maximum Cable Length: 100m/300ft on Category 5 cable between device and Ethernet switch Power and Dimensions: Mains Voltage: 100-240V AC, 50/60Hz Power Consumption: <35VA BTU Rating: <188 BTU/hr Operating Temperature Range: 0º to 45º C (32º to 113º F) Dimensions (H(U) x W x D): 1.75″ (1U) x 19″ x 12.5″ (45mm x 483mm x 318mm) Eligible for next day delivery or collection Free Delivery Available on Order From R2999 Hassle-Free Exchanges & Return for 30 Days 12-Month Limited Warranty. Category: Audio Equipment Tag: Soundweb
